1. What is one advantage of using the cut-through switching method instead of the store-and-forward switching method?
   has a positive impact on bandwidth by dropping most of the invalid frames
   makes a fast forwarding decision based on the source MAC address of the frame
   has a lower latency appropriate for high-performance computing applications​*
   provides the flexibility to support any mix of Ethernet speeds
2. A network designer must provide a rationale to a customer for a design which will move an enterprise from a flat network topology to a hierarchical network topology. Which two features of the hierarchical design make it the better choice? (Choose two.)
   reduced cost for equipment and user training
   less required equipment to provide the same performance levels
   simpler deployment for additional switch equipment*
   easier to provide redundant links to ensure higher availability*
   lower bandwidth requirements
3. What are two advantages of modular switches over fixed-configuration switches? (Choose two.)
   availability of multiple ports for bandwidth aggregation
   lower forwarding rates
   need for fewer power outlets*
   lower cost per switch
   increased scalability*
4.


   Refer to the exhibit. Consider that the main power has just been restored. PC1 asks the DHCP server for IPv4 addressing. The DHCP server sends it an IPv4 address. While PC2 is still booting up, PC3 issues a broadcast IPv4 DHCP request. To which port will SW1 forward this request?​
   to Fa0/1, Fa0/2, and Fa0/4 only​
   to Fa0/1, Fa0/2, Fa0/3, and Fa0/4
   to Fa0/1 and Fa0/2 only
   to Fa0/1, Fa0/2, and Fa0/3 only*
   to Fa0/1 only​
5. What is one function of a Layer 2 switch?
   forwards data based on logical addressing
   learns the port assigned to a host by examining the destination MAC address
   duplicates the electrical signal of each frame to every port
   determines which interface is used to forward a frame based on the destination MAC address*
6.


   Refer to the exhibit. Fill in the blank.
   There are ” 12 ” collision domains in the topology.​
7. What is a collapsed core in a network design?
   a combination of the functionality of the access, distribution, and core layers
   a combination of the functionality of the access and core layers
   a combination of the functionality of the distribution and core layers*
   a combination of the functionality of the access and distribution layers
8. What are two reasons a network administrator would segment a network with a Layer 2 switch? (Choose two.)
   to enhance user bandwidth*
   to eliminate virtual circuits
   to create more broadcast domains
   to isolate traffic between segments*
   to isolate ARP request messages from the rest of the network
   to create fewer collision domains
9.


   Refer to the exhibit.
   How is a frame sent from PCA forwarded to PCC if the MAC address table on switch SW1 is empty?
   SW1 forwards the frame directly to SW2. SW2 floods the frame to all ports connected to SW2, excluding the port through which the frame entered the switch.
   SW1 floods the frame on all ports on the switch, excluding the interconnected port to switch SW2 and the port through which the frame entered the switch.
   SW1 floods the frame on all ports on SW1, excluding the port through which the frame entered the switch.*
   SW1 drops the frame because it does not know the destination MAC address.
10. Place the options in the following order:
    [+] appropriate for high performance computing applications
    [+] forwarding process can begin after receiving the destination address
    [+] may forward invalid frames
    [#] error checking before forwarding
    [#] forwarding process only begin after receiving the entire frame
    [#] only forward valid frames
    [+] Order does not matter within this group.
    [#] Order does not matter within this group.
11. What is a basic function of the Cisco Borderless Architecture distribution layer?aggregating Layer 3 routing boundaries*aggregating all the campus blocks
    acting as a backbone
    providing access to the user
12. ABC, Inc. has about fifty hosts in one LAN. The administrator would like to increase the throughput of that LAN. Which device will increase the number of collision domains and thereby increase the throughput of the LAN?hub
    host
    NIC
    switch*
13. What does the term “port density” represent for an Ethernet switch?
    the numbers of hosts that are connected to each switch port
    the speed of each port
    the memory space that is allocated to each switch port
    the number of available ports*
14. Which type of transmission does a switch use when the destination MAC address is not contained in the MAC address table?
    anycast
    unicast
    broadcast*
    multicast
15. What is a basic function of the Cisco Borderless Architecture access layer?aggregates Layer 3 routing boundaries
    provides high availability
    aggregates Layer 2 broadcast domains
    provides access to the user*
16. What information is added to the switch table from incoming frames?
    source MAC address and incoming port number*
    destination MAC address and incoming port number
    destination IP address and incoming port number
    source IP address and incoming port number
17. Fill in the blank.
    A     “converged”     network is one that uses the same infrastructure to carry voice, data, and video signals.
18. An administrator purchases new Cisco switches that have a feature called StackPower. What is the purpose of this feature?It enables many switches to be connected with a special fiber-optic power cable to provide higher bandwidth.
    It enables the sharing of power among multiple stackable switches.*
    It enables many switches to be connected to increase port density.
    It enables many switches to be physically stacked in an equipment rack.
    It enables AC power for a switch to be provided from a powered patch panel.
19. Which switch form factor should be used when large port density, fault tolerance, and low price are important factors?fixed-configuration switch
    modular switch
    stackable switch*
    rackable 1U switch
20.





    Refer to the exhibit. Fill in the blank.
    There are     ”  5  ”   broadcast domains in the topology.​
